STP60N3LH5

STP60N3LH5 Overview

This product is manufactured by STMicroelectronics. The product can operate at a maximum temperature of Through Hole. TO-220-3 package/case type is utilized by this product. This product is equipped with 1 Channel for efficient performance. Vds rating of 30 V 48 A continuous drain current Rds On value of 7.2 mOhms Gate-Source Threshold Voltage Range: 3 V Gate-Source Voltage: 22 V The product can operate at a maximum temperature of + 175 C. 60 W This product has a Single configuration. Tube packaging for easy dispensing The Transistor Type is 1 N-Channel. This device belongs to the N-Channel STripFET V Power MOSFET type. STMicroelectronics is a trusted brand for quality electronics Minimum forward transconductance of 1.1 S 4.2 ns fall time MOSFET product type Rise Time is 33 ns. 1000 of 100 MOSFETs as subcategory Turn-off delay time is 19 ns. The typical turn-on delay time is 6 ns. 1. 0.011640 oz of Unit Weight

STP60N3LH5 Image

STP60N3LH5 Specifications

• Manufacturer: STMicroelectronics
• Product Category: MOSFET
• RoHS: Y
• Technology: Si
• Mounting Style: Through Hole
• Package / Case: TO-220-3
• Number of Channels: 1 Channel
• Transistor Polarity: N-Channel
• Vds - Drain-Source Breakdown Voltage: 30 V
• Id - Continuous Drain Current: 48 A
• Rds On - Drain-Source Resistance: 7.2 mOhms
• Vgs th - Gate-Source Threshold Voltage: 3 V
• Vgs - Gate-Source Voltage: 22 V
• Qg - Gate Charge: 8.8 nC
• Maximum Operating Temperature: + 175 C
• Pd - Power Dissipation: 60 W
• Configuration: Single
• Packaging: Tube
• Series: STP60N3LH5
• Transistor Type: 1 N-Channel
• Type: N-Channel STripFET V Power MOSFET
• Brand: STMicroelectronics
• Forward Transconductance - Min: 1.1 S
• Fall Time: 4.2 ns
• Product Type: MOSFET
• Rise Time: 33 ns
• Factory Pack Quantity: 1000
• Subcategory: MOSFETs
• Typical Turn-Off Delay Time: 19 ns
• Typical Turn-On Delay Time: 6 ns
• Unit Weight: 0.011640 oz
