TLC070AIP

TLC070AIP Overview

This product is manufactured by Texas Instruments. The product can operate at a maximum temperature of Through Hole. PDIP-8 package/case type is utilized by this product. Supply Voltage - Max: 16 V This product is equipped with 1 Channel for efficient performance. This product has a 80 dB to 95 dB of 50 dB, ensuring reliable signal acquisition. This product has an 50 pA of 5 uA for precise signal processing. Supply Voltage - Min: 4.5 V The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 125 C. This product does not have a Shutdown feature, ensuring continuous operation. Tube packaging for easy dispensing The amplifier type is Wideband Amplifier. The height of the product is 4.57 mm. 9.81 mm long Precision Amplifiers Supply Type: Single, Dual Texas Instruments is a trusted brand for quality electronics THD plus Noise value is 0.022 %. The 0.6 fA/sqrt Hz is 0.7 pA/rtHz. 1. The maximum dual supply voltage is +/- 8 V. +/- 2.25 V minimum dual supply voltage 4.5 V to 16 V, +/- 2.25 V to +/- 8 V operating supply voltage range 1.2 W Op Amps - Operational Amplifiers product type 50 of 100 Amplifier ICs as subcategory 1. 0.015535 oz of Unit Weight

TLC070AIP Image

TLC070AIP Specifications

• Manufacturer: Texas Instruments
• Product Category: Operational Amplifiers - Op Amps
• RoHS: Y
• Mounting Style: Through Hole
• Package / Case: PDIP-8
• Supply Voltage - Max: 16 V
• Output Current per Channel: 57 mA
• Number of Channels: 1 Channel
• GBP - Gain Bandwidth Product: 10 MHz
• SR - Slew Rate: 16 V/us
• CMRR - Common Mode Rejection Ratio: 80 dB to 95 dB
• Ib - Input Bias Current: 50 pA
• Vos - Input Offset Voltage: 1.4 mV
• Supply Voltage - Min: 4.5 V
• Operating Supply Current: 1.9 mA
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Shutdown: Shutdown
• Series: TLC070A
• Packaging: Tube
• Amplifier Type: Wideband Amplifier
• Features: Shutdown
• Height: 4.57 mm
• Length: 9.81 mm
• Product: Precision Amplifiers
• Supply Type: Single, Dual
• Technology: BiCMOS
• Width: 6.35 mm
• Brand: Texas Instruments
• THD plus Noise: 0.022 %
• Dual Supply Voltage: +/- 3 V, +/- 5 V
• en - Input Voltage Noise Density: 12 nV/sqrt Hz
• In - Input Noise Current Density: 0.6 fA/sqrt Hz
• Ios - Input Offset Current: 700 pA
• Maximum Dual Supply Voltage: +/- 8 V
• Minimum Dual Supply Voltage: +/- 2.25 V
• Operating Supply Voltage: 4.5 V to 16 V, +/- 2.25 V to +/- 8 V
• Pd - Power Dissipation: 1.2 W
• Product Type: Op Amps - Operational Amplifiers
• Factory Pack Quantity: 50
• Subcategory: Amplifier ICs
• Voltage Gain dB: 120 dB
• Unit Weight: 0.015535 oz
