AD829ARZ

AD829ARZ Overview

Product belongs to the AD829 series. This product is categorized as Video Amplifiers Tube Alternate Packaging is the packaging method for this product Weight of 0.019048 oz SMD/SMT Mounting-Style SOIC-8 BiCOM is the technology used. The No for this product is CMOS/TTL. Surface Mount mounting type Output-Type: No Versatile Voltage Feedback applications for maximum usability Number of channels: 1 Channel Supplier device package: 8-SOIC 1 is 8. Voltage supply range: ±4.5 V ~ 18 V This product has a 5.3mA of 200μA. The 120MHz The 230 V/μs. Current-Output-Channel is 32mA The amplifier is of General Purpose Amplifier type. Power-off control: No Shutdown Power-off control: 900 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C The AD829AR-EBZ. Input bias current of 7 uA The 1 mV. The 98 dB. The CMRR-Common-Mode-Rejection-Ratio is 100 dB. The 1.7 nV/sqrt Hz of this product is 110 nV/sqrt Hz. 600 MHz is the 3-dB bandwidth of the product. 96.26 dB voltage gain

AD829ARZ Image

AD829ARZ Specifications

• Manufacturer Analog Devices Inc.
• Product Category Linear - Amplifiers - Video Amps and Modules
• Series AD829
• Product Video Amplifiers
• Packaging Tube Alternate Packaging
• Unit-Weight 0.019048 oz
• Mounting-Style SMD/SMT
• Package-Case SOIC-8
• Technology BiCOM
• Input-Type No
• Mounting-Type Surface Mount
• Output-Type No
• Applications Voltage Feedback
• Number-of-Channels 1 Channel
• Supplier-Device-Package 8-SOIC
• Number-of-Circuits 1
• Voltage-Supply-Single-Dual ±4.5 V ~ 18 V
• Current-Supply 5.3mA
• -3db-Bandwidth 120MHz
• Slew-Rate 230 V/μs
• Current-Output-Channel 32mA
• Amplifier-Type General Purpose Amplifier
• Shutdown No Shutdown
• Pd-Power-Dissipation 900 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Development-Kit AD829AR-EBZ
• Ib-Input-Bias-Current 7 uA
• Vos-Input-Offset-Voltage 1 mV
• PSRR-Power-Supply-Rejection-Ratio 98 dB
• CMRR-Common-Mode-Rejection-Ratio 100 dB
• GBP-Gain-Bandwidth-Product 600 MHz
• SR-Slew-Rate 150 V/us
• en-Input-Voltage-Noise-Density 1.7 nV/sqrt Hz
• 3-dB-Bandwidth 600 MHz
• Voltage-Gain-dB 96.26 dB
