ADC14V155CISQ

ADC14V155CISQ Overview

Product belongs to the ADC14V155 series. This product is categorized as Analog to Digital Converters Type: S/H ADC Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style WQFN-48 The Differential for this product is CMOS/TTL. Operational temperature range: -40°C ~ 85°C Number of channels: 1 Channel Supplier device package: 48-WQFN (7x7) This product's 155M. Data-Interface: LVDS - Parallel 14 bits The Voltage-Supply-Analog is 3 V ~ 3.6 V. The Voltage Supply Digital for this product is 3 V ~ 3.6 V. Configuration S/H-ADC The architecture of this product is Pipelined . External, Internal is the reference type. 1 units Power-off control: 5.2 W Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Parallel interface type Signal-to-Noise Ratio of 71.9 dB The ADC14V155HFEB/NOPB. The 3.2 % FSR of this product is 0.2%. Number-of-Converters: 1 Converter 155 MS/s Sampling Rate Analog supply voltage: 3.3 V Digital Supply Voltage: 1.6 V to 3.6 V Integral Nonlinearity: 5 LSB Differential nonlinearity: - 1 LSB to + 1.1 LSB

ADC14V155CISQ Image

ADC14V155CISQ Specifications

• Manufacturer Texas Instruments
• Product Category Data Acquisition - Analog to Digital Converters (ADC)
• Series ADC14V155
• Product Analog to Digital Converters
• Type S/H ADC
• Packaging Digi-ReelR Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case WQFN-48
• Input-Type Differential
• Operating-Temperature -40°C ~ 85°C
• Features -
• Number-of-Channels 1 Channel
• Supplier-Device-Package 48-WQFN (7x7)
• Sampling-Rate-Per-Second 155M
• Data-Interface LVDS - Parallel
• Number-of-Bits 14
• Voltage-Supply-Analog 3 V ~ 3.6 V
• Voltage-Supply-Digital 3 V ~ 3.6 V
• Configuration S/H-ADC
• Architecture Pipelined
• Number-of-Inputs 1
• Resolution 14 bit
• Reference-Type External, Internal
• Ratio-S-H:ADC 1899/12/30 1:01:00
• Number-of-A-D-Converters 1
• Pd-Power-Dissipation 5.2 W
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Interface-Type Parallel
• SNR-Signal-to-Noise-Ratio 71.9 dB
• Development-Kit ADC14V155HFEB/NOPB
• Gain-Error 3.2 % FSR
• Number-of-Converters 1 Converter
• Sampling-Rate 155 MS/s
• Analog-Supply-Voltage 3.3 V
• Digital-Supply-Voltage 1.6 V to 3.6 V
• INL-Integral-Nonlinearity 5 LSB
• DNL-Differential-Nonlinearity - 1 LSB to + 1.1 LSB
