HMC452ST89E

HMC452ST89E Overview

Product belongs to the HMC452 series. Type: RF Amplifier Cut Strip Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style SOT-89-4 This product's 400MHz ~ 2.2GHz range is 0Hz to 2.2GHz. GaAs InGaP is the technology used. Frequency Bandwidth: 0.4 GHz to 2.2 GHz Number of channels: 1 Channel Voltage Supply Range: 5V Supplier device package: * This product has a 510mA of 200μA. The device offers a 9dB of 26dB. The amplifier is of Power type. Test-Frequency is 2.1GHz. P1dB is 31.5dBm RF-Type: General Purpose Power-off control: 2.7 W Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 5 V supply voltage for reliable performance. 510 mA is 92 nA. The operating frequency is 2.2 GHz. NF-Noise-Figure is 7 dB 49 dBm OIP3 third-order intercept The 22 dB is 12 dB.

HMC452ST89E Image

HMC452ST89E Specifications

• Manufacturer Analog Devices Inc.
• Product Category RF Amplifiers
• Series HMC452
• Type RF Amplifier
• Packaging Cut Strip Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case SOT-89-4
• Frequency 400MHz ~ 2.2GHz
• Technology GaAs InGaP
• Frequency-Range 0.4 GHz to 2.2 GHz
• Number-of-Channels 1 Channel
• Voltage-Supply 5V
• Supplier-Device-Package *
• Current-Supply 510mA
• Gain 9dB
• Amplifier-Type Power
• Test-Frequency 2.1GHz
• P1dB 31.5dBm
• Noise-Figure 6.5dB
• RF-Type General Purpose
• Pd-Power-Dissipation 2.7 W
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Operating-Supply-Voltage 5 V
• Operating-Supply-Current 510 mA
• Operating-Frequency 2.2 GHz
• NF-Noise-Figure 7 dB
• P1dB-Compression-Point 31.5 dBm
• OIP3-Third-Order-Intercept 49 dBm
• Input-Return-Loss 22 dB
