| Mfr. #: | M74HC244TTR |
|---|---|
| Hersteller: | STMicroelectronics |
| Beschreibung: | Buffers & Line Drivers Octal Bus Buffe |
| Lebenszyklus: | Neu von diesem Hersteller. |
| Datenblatt: | M74HC244TTR Datenblatt |
Product belongs to the 74HC series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.014850 oz SMD/SMT Mounting-Style TSSOP-48 Operational temperature range: -55°C ~ 125°C Surface Mount mounting type Output-Type: 3-State Number of channels: 8 Voltage Supply Range: 2 V ~ 6 V Supplier device package: 20-TSSOP 2 element Buffer/Line Driver, Non-Inverting logic type 4 bits per element Power-off control: 500 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 55 C Polarity: Non-Inverting Maximum supply voltage of 6 V Minimum supply voltage is 2 V HC logic type 130 ns at 2 V 26 ns at 4.5 V 22 ns at 6 V is 23 microseconds. High-Level-Output-Current of - 7.8 mA 7.8 mA low-level output current Number-of-Input-Lines: 8 Input Number-of-Output-Lines: 3 Output
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
M74HC244TTR Specifications
