| Mfr. #: | SN74123N |
|---|---|
| Hersteller: | Texas Instruments |
| Beschreibung: | Monostable Multivibrator Dual retrig monostbl multivibrators |
| Lebenszyklus: | Neu von diesem Hersteller. |
| Datenblatt: | SN74123N Datenblatt |
Product belongs to the 7400 series. Tube is the packaging method for this product Weight of 0.033570 oz Through Hole Mounting-Style PDIP-16 Operational temperature range: 0°C ~ 70°C Through Hole mounting type Voltage Supply Range: 4.75 V ~ 5.25 V Supplier device package: 16-PDIP Monostable logic type No. 2 Independent Circuit 22ns Propagation-Delay Maximum operating temperature of + 70 C Minimum operating temperature: 0 C This product operates at a 5 V supply voltage for reliable performance. Maximum supply current: 46 mA Maximum supply voltage of 5.25 V Minimum supply voltage is 4.75 V TTL logic type 40 ns is 23 microseconds. High-Level-Output-Current of - 0.8 mA 16 mA low-level output current 2 Elements-per-Chip
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
SN74123N Specifications
