| Mfr. #: | TL431BIDE4 |
|---|---|
| Hersteller: | Texas Instruments |
| Beschreibung: | Voltage References Adjustable Precision Shunt Regulato |
| Lebenszyklus: | Neu von diesem Hersteller. |
| Datenblatt: | TL431BIDE4 Datenblatt |
Product belongs to the TL431B series. Tube Alternate Packaging is the packaging method for this product Weight of 0.002561 oz SMD/SMT Mounting-Style SOIC-8 Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Output-Type: Adjustable Supplier device package: 8-SOIC Tolerance of ±0.5% - voltage input This product has a - of 200μA. Shunt is the reference type. Minimum fixed output voltage is 2.495V . 34 PPM / C is 30 parts per million per degree Celsius. - of noise in 0#1Hz-to-10Hz range Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Output voltage: Adjustable Initial accuracy: 0.5 % Maximum input voltage of 37 V for Series VREF. Maximum shunt current of 100 mA Maximum output voltage is 36 V . This product has a minimum 600 uA of 50 uA.
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
TL431BIDE4 Specifications
