TPD8S009DSMR

TPD8S009DSMR Overview

Product belongs to the TPD8S009 series. Type: Steering (Rail to Rail) Digi-ReelR Alternate Packaging is the packaging method for this product This product's Termination-Style is ' SMD/SMT ' for easy integration into your design. 15-SMD, No Lead Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Versatile HDMI applications for maximum usability Number of channels: 8 Channel Supplier device package: 15-SON 8 Bidirectional-Channels The Voltage-Reverse-Standoff-Typ is set at a maximum of 5.5V (Max). The Voltage-Breakdown-Min is 9V. No Power-Line-Protection - Capacitance-Frequency Power-off control: 25 W Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Breakdown-Voltage: 9 V The Cd-Diode-Capacitance is 0.8 pF 5.5 V working voltage Polarity: Bidirectional 8 kV of Vesd-Voltage-ESD-Contact 9 kV Vesd-Voltage-ESD-Air-Gap This product operates at a - 0.3 V to + 6 V supply voltage for reliable performance.

TPD8S009DSMR Image

TPD8S009DSMR Specifications

• Manufacturer Texas Instruments
• Product Category TVS - Diodes
• Series TPD8S009
• Type Steering (Rail to Rail)
• Packaging Digi-ReelR Alternate Packaging
• Termination-Style SMD/SMT
• Package-Case 15-SMD, No Lead
• Operating-Temperature -40°C ~ 85°C (TA)
• Mounting-Type Surface Mount
• Applications HDMI
• Number-of-Channels 8 Channel
• Supplier-Device-Package 15-SON
• Unidirectional-Channels -
• Bidirectional-Channels 8
• Voltage-Reverse-Standoff-Typ 5.5V (Max)
• Voltage-Breakdown-Min 9V
• Voltage-Clamping-Max-Ipp -
• Current-Peak-Pulse-10-1000μs -
• Power-Peak-Pulse 25W
• Power-Line-Protection No
• Capacitance-Frequency -
• Pd-Power-Dissipation 25 W
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 40 C
• Breakdown-Voltage 9 V
• Cd-Diode-Capacitance 0.8 pF
• Working-Voltage 5.5 V
• Polarity Bidirectional
• Vesd-Voltage-ESD-Contact 8 kV
• Vesd-Voltage-ESD-Air-Gap 9 kV
• Operating-Supply-Voltage - 0.3 V to + 6 V
