TPS2818MDBVREP

TPS2818MDBVREP Overview

Product belongs to the TPS2818-EP series. This product is categorized as MOSFET Gate Drivers Type: Low-Side Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.000459 oz SMD/SMT Mounting-Style SOT-23-5 Operational temperature range: 14ns, 14ns -55°C ~ 125°C (TA) mounting type Supplier device package: SC-74A, SOT-753 Resolution-Bits: 1 Data-Interface: Single The Voltage-Supply-Analog is Inverting. The Voltage Supply Digital for this product is -. Configuration Inverting 4 V ~ 14 V is supported. Number-of-Outputs: 1 Power-off control: 437 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 55 C 650 uA is 92 nA. Output current: 2 A This product has a 35 ns of 16 ns. This product has a 25 ns of 16 ns. This product is also known as V62/08601-03XE and can be referred to by either part number. Maximum supply voltage of 14 V Minimum supply voltage is 5 V Number-of-Drivers: 1 Driver

TPS2818MDBVREP Image

TPS2818MDBVREP Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Gate Drivers
• Series TPS2818-EP
• Product MOSFET Gate Drivers
• Type Low-Side
• Packaging Digi-ReelR Alternate Packaging
• Unit-Weight 0.000459 oz
• Mounting-Style SMD/SMT
• Package-Case SOT-23-5
• Operating-Temperature 14ns, 14ns
• Mounting-Type -55°C ~ 125°C (TA)
• Supplier-Device-Package SC-74A, SOT-753
• Resolution-Bits 1
• Data-Interface Single
• Voltage-Supply-Analog Inverting
• Voltage-Supply-Digital -
• Configuration Inverting
• Number-of-ADCs-DACs
• Sigma-Delta 4 V ~ 14 V
• S-N-Ratio-ADCs-DACs-db-Typ 1V, 4V
• Dynamic-Range-ADCs-DACs-db-Typ 2A, 2A
• Number-of-Outputs 1
• Pd-Power-Dissipation 437 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 55 C
• Operating-Supply-Current 650 uA
• Output-Current 2 A
• Fall-Time 35 ns
• Rise-Time 25 ns
• Part-#-Aliases V62/08601-03XE
• Supply-Voltage-Max 14 V
• Supply-Voltage-Min 5 V
• Number-of-Drivers 1 Driver
