The core of a solar cell is the photovoltaic effect. When sunlight (photons) hits a semiconductor material, and the photon energy is higher than the material's bandgap, it can free electrons from atoms. This creates electron-hole pairs that can move in a certain direction.
The key structure is the PN junction. Its built-in electric field quickly separates the excited carriers: electrons go to the N-type area, and holes go to the P-type area. After connecting electrodes, the flow forms a current (see: carrier separation model). This physical process directly changes light energy into DC electricity.
There are different technical paths to meet different needs:
| Technology Type | Main Feature | Key Advantage | Main Limitation |
| Monocrystalline Silicon (Mono-Si) | High purity single crystal silicon | High conversion efficiency (24–26%), good space use, long life | High energy cost to produce, limited area per unit power |
| Polycrystalline Silicon (Poly-Si) | Clustered silicon crystals | Better price-performance ratio, simpler production | Lower efficiency (20–22%), weak in high temperatures |
| Thin Film Cells | |||
| ▪ Amorphous Silicon (a-Si) | Silicon atoms in random order | Works well in low light, flexible to make | Low efficiency (6–10%), light-induced decay |
| ▪ Cadmium Telluride (CdTe) | CdTe semiconductor layer | Very low cost potential, good temperature stability | Cadmium needs special recycling, tellurium is rare |
| ▪ Copper Indium Gallium Selenide (CIGS) | CuInGaSe₂ compound | High efficiency potential (23%), flexible, good in weak light | Complex process, low yield, rare indium/gallium |
Conversion efficiency means the percent of sunlight turned into electricity:
Main limitations include physical limits (single-junction max is ~33%), carrier recombination loss, optical reflection, and resistance loss.
Most silicon cells use visible light (380–750 nm). They use near-infrared poorly and UV light even worse (see absorption curve: silicon has peak response in visible range). To use more spectrum, multi-junction technology is needed.
When shadows or damage affect part of a panel, that cell becomes a load, not a generator. Good cells then push reverse current through the bad one, heating it a lot (thermal images show red dots). In extreme cases, it can melt or catch fire.
Initial cost includes modules (~50%), inverter, support structures, electrical parts, installation, and grid connection.
Use tools (like PVSol) to choose site properly:
Government policies affect profits:
New building codes require rooftops to support solar loads (see policy timeline getting stricter each year).
You must balance six areas when deciding panel quantity (see decision radar chart):
Solar power replaces fossil fuels in 3 ways:
We must manage the full lifecycle:
Circular economy supports 3 new trends:
To calculate how many solar panels you need, consider your home's daily energy usage (kWh), available peak sun hours, your chosen panel's wattage, and its efficiency. The calculation is:Number of Panels = Daily Energy Consumption (kWh) / [Panel Wattage (kW) × Peak Sun Hours × Efficiency](Note: Converting Wattage to kW improves unit consistency)
Determining the solar panel count for a 2000 sq ft home involves factors such as electricity usage, local sunlight, panel efficiency, and system losses, with a typical range being 16 to 21 panels.
Running an air conditioner using solar panels is possible; however, it necessitates careful planning, taking into account factors such as the AC unit's size, geographical location, and the solar system configuration (on-grid or off-grid).
Solar panels typically have a lifespan of 25 to 30 years or longer, experiencing a gradual decline in efficiency over time. Nevertheless, they continue to generate significant power output for many years.
